>AZURE- 6550TSMD
Specification
Working Distance :  65mm
Magnification :  5x
Mount : C
Effective F/No:  34.07
Format :  1/2"
Depth of Field : 0.11mm
Field Range: 1.28mm
TV Distortion :  0.0028%
>> Dimension
>> MTF Curves
