Products >> Machine Vision Lenses >> Fixed Mega-pixel Large Format Lenses
>> Item No : AZURE-2520ML5M
Specification
Focal Length :  25mm
Resolution: 5 mega-pixel
Back Focus :  11.94mm
Mount : C
F/No : 2.0
Format :  1
Angle of View (V) 34.6
Iris Type :  Manual Iris
Distortion : <-0.12%
Focusing range : ~  0.3m
IR Correction : OK
Coating Range: 400nm~950nm
Dimension :  46 x 65.82mm
Filter thread : M43 x 0.75mm
Weight : 300g
Dimension
MTF Curves
